Foot switches

//

Series GF, variants

Features/Options - With Hall sensor: Analogue output - Metal enclosure - Various output values available: 0 … 10 VDC, 0 … 20 mA or 4 … 20 mA - Analogue output signal proportional to pedal travel - Without protective shield - Available with additional micro switch - High level of stability - Low pedal height - Wiring compartment - Available with special finish in RAL colour tonesStandards IEC/EN 60947-5-1 Enclosure aluminium die-cast, enamel finish, RAL 5011 Cover glass-fibre reinforced thermoplastic Pedal glass-fibre reinforced thermoplastic Protective shield – Termination screw terminals Cable entry M20 x 1.5 Protection class IP 65 to EN 60529

//

GF HS

Switching system

Technical data

Hall sensor 0...10 VDC ±1 % Output values Output voltage Ua Output current Ia 0...20 mA ±1 % or 4...20 mA ±1 % Utilisation category – Ie/Ue with Ua: 25 mA/15 … 30 VDCwith Ia: 45 mA/15 … 30 VDC Max. industrial fuse rating – Ambient temperature – 10 °C … + 70 ºC Mechanical life > 1 million operations
16 Contact variants: Travel/contacts Ordering detailsGF HS 0…20 mA Hall sensor Output value Ia0…20 mA (Ia4…20 mA, Ua0…10 VDC)Hall sensor Series Ua GF HS 0…10 VDC Ia GF HS 0…20 mAGF HS 4…20 mA
