Features/Options - With latching: ON/OFF principle - Max. 2 contacts - Metal enclosure - Without protective shield - High level of stability - Low pedal height - Wiring compartment - Available with special finish in RAL colour tonesStandards IEC/EN 60947-5-1 Enclosure aluminium die-cast, enamel finish, RAL 5011 Cover glass-fibre reinforced thermoplastic Pedal glass-fibre reinforced thermoplastic Protective shield –

//

GF RE

Termination

Technical data

screw terminals Wire cross-section max. 2.5 mm
2 (incl. conductor ferrules) Cable entry M20 x 1.5 Contact material silver Protection class IP 65 to EN 60529 Switching system slow action with double break, positive breakNC contact A Switch insert ES 60 GF RE Switching element 1 NC/1 NO contact with latching Utilisation category AC-15 Ie/Ue 16 A/400 VAC Max. industrial fuse rating 16 A gL/gG D-fuse
15 Ambient temperature – 25 °C … + 80 ºC Mechanical life > 1 million operations Approvals

H

Contact variants: Travel/contacts Ordering detailsGF 1Ö/1S RE Slow action Latching element1NC/1NO contactSeries 1 NC/1 NO contact GF 1Ö/1S RE
