Orderingdetails

Ex switchgear Safety switches manufacturers Pneumatic interlocks EEx AZP 415 range 1.1.2 1.2.2

EEx interlock, actuated with industrial air supply off, with pneumatic cy-linder, two NO and two NC contacts: EEx AZP 415 2Ö/2S Actuators manufacturers and accessories must be ordered separately, e.g. straight actuator: AZ/AZM 415-B1 Info Further variants not shown here are available on enquiry.The applicable ordering suffix is added at the end of the part number of the safety switch.• Available with gold-plated contacts Actuationwith air supply offEEx AZP 415-22zpk 2 NO 2 NCContacts Note The contacts 11-12 and 23-24 of the switch insert S1 are actuated on air supply being connected to or disconnected from the pneumatic cylinder manufacturers P1. Circuit diagrams show condition without air supply, with actuator inserted (0 in switch travel diagram). Actuators must be ordered separately. A selection of suitable actuators and accessories can be found on the followingpages.
