1. 1.1 1.1.8 EEx 355 AZEEx ST 61

Standards:IEC/EN 60947-5-1; EN 1088EN 50014; EN 50018; EN 50019; EN 50281-1-1EN 50014; EN 50018; EN 50281-1-1 Ex marking:

L

II 2G EEx de IIC T6

L

II 2G EEx d IIC T6II 2D IP67 T80°CII 2D IP65 T80°C Certification : BVS 04 ATEX E 126PTB 03 ATEX 1068 X *Enclosure material:Zinc die-cast, enamel finishAluminium die-cast, enamel finish Switch insert:EEx 95EEx 13 Actuator manufacturer:Stainless steel 1.4301Protection class:IP 67 to IEC/EN 60529IP 65 to IEC/EN 60529 Contact material:Silver Contact type:Change-over contact with double break Zb or 2 NC contactsChange-over contact with double break Zb Switching system: A IEC 60947-5-1; slow action, NC contact with positive breakTermination:M3 screw terminals, wire max. 1.5 mm
2 Pre-wired cable H05VV-F 4 x 0.75 mm
2 (incl. conductor ferrules)Cable length:–3 m Rated impulse withstand voltage U
imp :4 kV Rated insulation voltage U
i :250 V Thermal test current I
the :6 AUtilisation category:AC-15; DC-13 Rated operating current/voltage I
e /U
e :6 A/250 VAC; 0.25 A/230 VDC Max. fuse rating:6 A gL/gG D-fuse Positive break travel:7 mm12 mm Ambient temperature:–20 °C … +60 ºC–20 °C … +65 ºC Mechanical life:>1 million operations* referring to the switch insert
0158

35 Ex switchgearSafety switches Protection switches with separate actuator Technical data
