Ex switchgearSafety switches Protective switches with separate actuator specifications Technical data 1. 1.1 1.1.8 EEx 95 AZEEx 335 AZ

Standards:IEC/EN 60947-5-1; EN 1088EN 50014; EN 50018; EN 50019; EN 50281-1-1 Ex marking:

L

II 2G EEx de IIC T6

L

II 2G EEx de IIC T6 II 2D IP67 T80°CII 2D IP65 T80°C Certification : DMT 01 ATEX E 118DMT 01 ATEX E 178 Enclosure material:Glass-fibre reinforced thermoplastic, Zinc die-cast, enamel finish self-extinguishingSwitch insert:–EEx 95 Actuator:Stainless steel 1.4301 Protection class:IP 67 to IEC/EN 60529 IP 65 to IEC/EN 60529 Contact material:Silver Contact type:Change-over contact with double break Zb or 2 NC contacts Switching system: A IEC 60947-5-1; slow action, NC contact with positive breakTermination:M3 screw terminals, wire max. 1.5 mm
2 (incl. conductor ferrules)Cable length:– Rated impulse withstand voltage U
imp :4 kV Rated insulation voltage U
i :250 V Thermal test current I
the :6 AUtilisation category:AC-15 Rated operating current/voltage I
e /U
e :6 A/250 V Max. industrial fuse rating:6 A gL/gG D-fuse Positive break travel:9 mm7 mm Ambient temperature:–20 °C … +60 ºC Mechanical life:>1 million operations* referring to the switch insert
0158

34
