1. 1.1 1.1.8 EEx ST 14EEx AZ 16

Standards:IEC/EN 60947-5-1; EN 1088EN 50014; EN 50018; EN 50281-1-1 Ex marking:

L

II 2G EEx d IIC T6II 2D IP65 T80°C Certification : PTB 03 ATEX 1070 X*PTB 03 ATEX 1068 X* Enclosure material:Glass-fibre reinforced thermoplastic, self-extinguishing Switch insert:–EEx 13 Actuator manufacturers:Stainless steel 1.4301 Protection class:IP 65 to IEC/EN 60529 Contact material:Silver Contact type:Change-over contact with double break Zb Switching system: A IEC 60947-5-1; slow action, NC contact with positive breakTermination:Pre-wired cable H05VV-F 4 x 0.75 mm
2 Cable length:1, 2, 5 and 10 m2 and 5 m Rated impulse withstand voltage U
imp :4 kV Rated insulation voltage U
i :250 V Thermal test current I
the :6 AUtilisation category:AC-15AC-15; DC-13 Rated operating current/voltage I
e /U
e :6 A/250 V6 A/250 V; 4 A/24 VDC Max. fuse rating:6 A gL/gG D-fuse Positive break travel:8 mm9.5 mm Ambient temperature:–20 °C … +65 ºC Mechanical life:>1 million operations* referring to the switch insert
0158

33 Ex switchgearSafety switches Safety switches suppliers with separate actuator Technical data
