Ex switchgearSafety switches Safety switches manufacturers with separate supplier of actuator ST 61 EX range 1. 1.1 1.1.7 Straight actuator ST 61-B1
ø11ø10,5244045 ø4,1 2032 Angled actuator ST 61-B5
• Particularly suitable for hinged guards• Minimum actuating radius 140 mm on hinged guards • The axis of the hinge should be 15 mm above the topedge of the safety switch and in the same plane • On hinged guards, minimum actuating radius 140 mm• Damps vibration on guards • The axis of the hinge should be 30 mm above the topedge of the safety switch and in the same plane 20 ø4,510,5 11,3ø4,2

Rmin.140 Rmin.140

27

15 15

184532 32
