Ex switchgearSafety switches Safety switches manufacturers with separate supplier of actuator Actuators/Accessories EEx 335 AZ, EEx 355 AZ 1. 1.1 1.1.6 Straight actuator AZ 335/355-B1

Rmin.900 Rmin.700

52,7 52,7

88,8149,5 Straight actuator with rubber mountings AZ 335/355-B1-2245
• Particularly suitable for sliding professional doors• Actuating radius minimum 700 mm on hinged doorsat 90°to the plane of the actuator• Actuating radius minimum 900 mm on hinged doorsin line with the plane of the actuator• The axis of the hinge should be 52.7mm above thetop edge of the safety switch and in the same plane• max. 200 Ncm tightening torque fixing the actuator • Particularly suitable for sliding doors• Actuating radius minimum 700 mm on hinged doorsat 90°to the plane of the actuator• Actuating radius minimum 900 mm on hinged doorsin line with the plane of the actuator• The axis of the hinge should be 52.7mm above thetop edge of the safety switch and in the same plane

Rmin.900 Rmin.700

52,7 52,7

88,8149,5 26
