By turning the head in 90°steps, 8 actuating planes arepossible. A Torx T10 bolting is needed for this purpose.Even when the screw is removed, the head is self-retaining.The switch can thus not be tampered with. Orderingdetails Actuatinghead To order, select the part number of the desired switch from the table “Contacts/Switch travel”, e.g. safety switch with one NO and one NC contact: EEx 355 AZ 1Ö/1SActuators and accessories must be ordered separately,e.g. straight actuator supplier: AZ 335/355/95-B1The applicable ordering suffix is added at the end of the part number of the safety switch. Further variants not shown here are available on request. Approvals EC Type Test Certificate: BVS 04 ATEX E 126

25 Ex switchgearSafety switches Safety switches with separate actuator EEx 355 AZ range
