By turning the head in 90°steps, 8 actuating planes arepossible. A Torx T10
bolting is needed for this purpose.Even when the screw is removed, the head is self-retaining.The switch can thus not be tampered with. Orderingdetails
Actuatinghead To order, select the part number of the desired switch from the table “Contacts/Switch travel”, e.g. safety switch
with one NO and one NC contact: EEx 335 AZ 1Ö/1SActuators and accessories must be ordered separately,e.g. straight actuator: AZ 335/355-B1The applicable ordering suffix is added at the end of the part number of the safety switch.
Further variants not shown here are available on request. Approvals EC Type Test Certificate: DMT 01 ATEX E 178
