1. 1.1 1.1.3 Straight actuator specifications 95 AZ-B1
• On hinged guards, minimum actuating radius 350 mm• Damps vibration on guards • The axis of the hinge should be 11 mm above the topedge of the safety switch and in the same plane • Particularly suitable for hinged guards• Minimum actuating radius 350 mm on hinged guards • The axis of the hinge should be 13.5 mm above thetop edge of the safety switch and in the same plane Angled actuator 95 AZ-B5 21 Ex switchgearSafety switches Protective switches with separate actuator EEx 95 AZ range
