Ex switchgearMagnetic sensors EEx RC 15 range 6. 6.1

• Nickel-plated brass enclosure•

L

II 2G EEx m II T6II 2D IP 67 T80°C• Long life • Proximity switching • 1 reed contact • Particularly resistant to vibration • Available for actuation from front • Any direction of operation possible • Actuating distance up to 25 mmdepending on actuating magnet• Pre-wired cable • IP 67 Cable length Info 1 metre longordering suffix-1m2 metres longordering suffix-2m5 metres longordering suffix-5mPlease always state cable length in orders Contacts 1 NC1 Change-over 1 NO EEx RC 15 1S Actuation from front EEx RC 15 1ÖEEx RC 15 1W Features NoteApprovals The actuating industrial magnets are not included with the sensors. For selection, see chapter 6.3. EC Type Test Certificate: DMT 01 ATEX E 058 X Version for equipment categories 3G and 3D(gas-Ex zone 2 and dust-Ex zone 22) available, Ordering suffix: -3G/D

291
