Features • Thermoplastic enclosure• II 2G EEx de IIC T6II 2D IP67 T80°C• Mounting dimensions to EN 50047 • Transversely slotted mounting holes • Double-insulated X • Slow action • Actuating head can be turned4 x 90°in factory• Cable entry M20 x 1.5 • Wiring compartment Info Version for equipment category 3D(dust-Ex zone 22) available Ordering suffix: -3D Approval EC type test certificate:DMT 01 ATEX E 118 Info Enclosure with vertically slotted mounting holes, ordering suffix LL 1 NO1 NC 2 NCEEx 95 AZ 2Ö Contacts/ Switch travel
23112412 11 211222 Note Inserted position of actuator = 0 in switch travel diagrams.Suppliers of actuators must be ordered separately. Standard version EEx 95 AZ 1Ö/1S Orderingdetails To order, select the part number of the desired switch from thetable “Contacts/Switch travel”, e.g. safety switch EEx 95 AZ with two NC contacts: EEx 95 AZ 2ÖActuators and accessories must be ordered separately,e.g. adjustable actuator: AZ 335/355/95-B6

20 Ex switchgearSafety switches Industrial safety switches with separate actuator EEx 95 AZ range
