5. 5.5 EEx GFSEEx GFS 2EEx GFS 3

Standards:IEC/EN 60947-5-1; EN 50014; EN 50018; EN 50281-1-1Ex marking:

L

II 2G EEx d IIC T6 II 2D IP65 T80°CCertification:EEx GFS: PTB 03 ATEX 1070 X*; EEx GFSM: PTB 03 ATEX 1069 X* Switch insert:EEx 14; EExM 14 Enclosure material:Aluminium die-cast, enamel finishAluminium cast, enamel finish Cover material:– Pedal material:Glass-fibre reinforced thermoplastic Protective shield material:Same like enclosure Termination:Cable H 05 VV-F 4 x 0.75 mm
2 , length 3 m Protection class:IP65 to IEC/EN 60529 Switching system:Snap or slow action Utilisation category:AC-15; DC-13 Rated operating current/voltage I
e /U
e :6 A/250 VAC; 0.25 A/230 VDCMax. industrial fuse rating:6 A gL/gG D-fuse Ambient temperature:–20 °C … +65 °C Mechanical life:> 1 million operations* referring to the switch insert
0158

288 288 Ex switchgearFoot switches Technical data
