Ex switchgearPosition switches Technical data 2. 2.5 EEx 13EEx 12EEx 95

Standards:IEC 60947-5-1; EN 1088; BG-GS-ET 15; EN 50014; EN 50018; EN 50281-1-1EN 50019 Ex marking:

L

II 2G EEx d IIC T6

L

II 2G EEx de IIC T6II 2D IP65 T80°CII 2D IP67 T80°C Certification:PTB 03 ATEX 1068 XPTB 03 ATEX 1067 XDMT 01 ATEX E 118 Switch insert:– Design:–EN 50047Enclosure:Thermoplastic, self-extinguishing aluminium die-cast, hard-coatedThermoplastic, self-extinguishing UL 94-VOUL 94-VOCover:Same as enclosure Protection class:IP 65 to IEC/EN 60529IP 67 to IEC/EN 60529 Contact material:Silver Switching system:Slow action,Snap actionSlow action, positive break NC contacts A positive break NC contacts A Contact type:Change-over contact, Change-over contact, Change-over contact, double break, galvanically single break double break with 2 separated separated contact bridgescontact bridgesTermination:H05VV-F 4 x 0.75 mm
2 H05VV-F 3 x 0.75 mm
2 M3 screw terminals, wire max. 1.5 mm
2 (including conductor ferrules)Rated impulse withstand voltage U
imp :4 kVRated insulationvoltage U
i :250 V Thermal test current I
the :6 A5 A6 AUtilisation category:AC-15;DC-13 Rated operating current/voltage I
e /U
e :6 A/250 VAC; 5 A/250 VAC; 6 A/250 VAC; 0.25 A/230 VDC0.16 A/230 VDC0.25 A/230 VDCMax. industrial fuse rating:6 A gL/gG D-fuse5 A gL/gG D-fuse6 A gL/gG D-fuse Ambient temperature:–25 °C … +65 °C–20 °C … +60 °CMechanical life:> 1 million operations Switching frequency:1800/hSwitching point accuracy:±0.1 mm Actuating speed:***– Contact break for complete stroke:**2 x 4.5 mm–2 x 3.5 mm Positive break force:see switch description Positive break stroke:see switch description Shock resistance:–*referring to the switch insert***for complete actuating stroke**referring to the switch plunger ****in accordance with actuating speed
