Ex switchgearPosition switches EEx 12 range 2. 2.3 Professional spring rod with rounded steel tip TF

ø7

82,58 Features • With rounded steel tip• Spring rod can be actuatedfrom any direction• Elasticity of the spring allows for deflection above the max. switching angle of 18° Version for equipment category 3D(dust-Ex zone 22) available Ordering suffix: -3D Contacts/ Switch travel Change-over Contact
2 BNBU14 BK Snap action

10°10°18°18°

1-4 1-2 EEx 12 TF Info Ordering details An EEx 12 range position switch with spring rod and roundedsteel tip TF, snap action with one change-over contact: EEx 12 TF

241
