Ex switchgearSafety switches Safety contactors with separate actuator supplier EEx AZ 16 range 1. 1.1 1.1.2 Straight actuator with ball latch AZ 15/16-B1-2053
• For interlocking of light to medium-weight guards• Latching force adjustable up to 100 N • Particularly suitable for sliding industrial doors • Minimum actuating radius on hinged guards 150 mm• The axis of the hinge should be 11 mm above the topedge of the safety switch and in the same plane

Rmin.150 Rmin.150

11 11

484014,7 81414 15
