Ex switchgearPosition switches EEx 12 range 2. 2.3 Long offset roller lever with watertight collar WHL

Features • Actuating speed 0.5 m/s with an actuatingangle of Legend : Actuating angle from right of switch axis = 40°and = 30°• Metal roller • Can be supplied with actuator supplier turned 180° • Collar over plunger to protectagainst ingress of dirt : Actuating angle from left of switch axis Note Actuation from the left should be avoided,since this reduces the mechanical life of the position switch. Version for equipment category 3D(dust-Ex zone 22) available Ordering suffix: -3D Contacts/ Switch travel Change-overContact
2 BNBU14 BK Snap action

3,8 11,50

1-4 1-2 EEx 12 WHL Info Info • Plastic roller available Ordering details An EEx 12 range position switch with long offset roller lever and watertight collar WHL, snap action with one change-over contact: EEx 12 WHL

237
