Ex switchgearSafety switches Protective switches with separate actuator manufacturer EEx AZ 16 range 1. 1.1 1.1.2 Adjustable actuator with magnetic latch AZ 15/16-B3-1747
• For play-free interlocking of light guards• Latching force 30 N • The magnetic latch can easily be fitted in anyactuating plane • Suitable for retrofitting • For very small actuating radii at 90°to the plane of the actuator• Actuating radius adjustable, minimum 32 mm, using a hexagonal key wrench 2.5 mm A/F (b)• The axis of the hinge should be 11 mm above the topedge of the safety switch and in the same plane

Rmin.32

11

402817,51,5 81410,5 14
