Ex switchgearSafety switches Safety switches suppliers with separate actuator suppliers EEx AZ 16 range 1. 1.1 1.1.2 Adjustable actuator with magnetic latch AZ 15/16-B2-1747
• For play-free interlocking of light guards• Latching force 30 N • The magnetic latch can easily be fitted in any actuating plane • Suitable for retrofitting • For very small actuating radii in line with the plane of the actuator• Actuating radius adjustable, minimum 45 mm, using a hexagonal key wrench 2.5 mm A/F (a)• The axis of the hinge should be 11 mm above the topedge of the safety switch and in the same plane

Rmin.45

11

402817,51,5 81410,5 13
