Ex switchgearPosition switches
EEx/EExM 14 and EExM 14 1Ö/1S range 2.
2.1
ø4,3 5098,4 416302220
50 ø7
Features Info • With overlapping contacts,ordering suffix 1Ö/1S UE• With cable on side, ordering suffix -s Approvals
Info • Thermoplastic enclosure• Double-insulated X EC Type test certificate: EEx 14: PTB 03 ATEX 1070 X
EExM 14: PTB 03 ATEX 1069 X
EExM 14 1Ö/1S: PTB 00 ATEX 1006 X •
L
II 2G EEx d IIC T6II 2D IP65 T80°C• Slow action A ,change-over contact, double break• Snap action, change-over contact, single or double break• Available with overlapping contacts
• Mountings to EN 50047
• Suitable for in-line mounting
• Pre-wired cable 1 m long
• IP 67 Note The switch must be protected from mechani-cal damage. Cable length Always specify cable length1 metre longordering suffix-1m
2 metres longordering suffix-2m5 metres longordering suffix-5m10 metres longordering suffix-10mOther lengths on enquiry Version for equipment category 3D(dust-Ex zone 22) available
Ordering suffix: -3D NoteA detailed description of the
actuators,as well as the contacts and switch travel diagrams, can be found in chapter 1.3.1. Plunger Plungerwith watertight collar W with front mounting F
Actuators
ø10 ø10 8,5 17,7 218
