EEx 14 RSSA

Standards:IEC/EN 60947-5-1;EN 50014; EN 50018; EN 50281-1-1EEx identification:

L

II 2G EEx d IIC T6, II 2D IP65 T80°CCertification:PTB 03 ATEX 1070 X Enclosure:Thermoplastic, self-extinguishing UL 94-VO Protection class:IP 65 to IEC/EN 60529 Contact material:Silver Switching system:Slow action NC contacts with positive break A Contact type:Change-over contact, double break Zb, with galvanically separated contact professional bridges Termination:Cable H 05VV-F 4 x 0.75 mm
2 Rated impulse withstand voltage U
imp :4 kVRated insulation voltage U
i :250 V Thermal test current I
the :6 AUtilisation category:AC-15; DC-13 Rated operating current/voltage I
e /U
e :6 A/250 VAC; 0.25 A/230 VDC Max. industrial fuse rating:6 A gL/gG D-fuse Ambient temperature:–20 °C … +65 °C Mechanical life:>1 million operations Switching frequency:1800/h Repeat operation accuracy:– Resistance to shock:50 g/6 ms
0158

214
