Ex switchgearSafety switches Emergency stop and push buttons EEx 14 range 1. 1.6 1.6.3 RW and RST selector and control switch

ø28

20251-7 Features • RW selector with rest positions• Cable length • Cable length 1 m • Other lengths on enquiry

L

II 2G EEx de IIC T6II 2D IP65 T80°C• 5 variants available • RST type with professional spring return • Pre-wired cable • RWA• With 2 rest positions • Switching angle 90°0 - I or I - II• RWB• With 3 rest positions • Switching angle 45°+ 45°I - 0 - II• RWC• Rest position to left • Spring return from right • Switching angle 45°+ 45°I - 0 II Approvals EC Type Test Certificate: PTB 03 ATEX 1070X Version for equipment category 3D(dust-Ex zone 22) available Ordering suffix: -3D RW actuatorsRSTactuators Legend • RSTA • Switching angle 90° • Spring return to left0 II • RSTB • Switching angle 45°+ 45° • Spring return to centreI 0 II Switch position Spring return Note Info The switch must be protected from mechanical damage.

210
