Ex switchgearSafety switches Safety switches with separate actuator manufacturers EEx AZ 16 range 1. 1.1 1.1.2 Adjustable actuator AZ 15/16-B6

Rmin.25 Rmin.38

11 11

Straight actuator with rubber mountings AZ 15/16-B1-2245
• Particularly suitable for sliding professional doors• Minimum actuating radius on hinged guards 150 mm• Damps vibration on guard devices • For very small actuating radii in line with or at 90°to the plane of the actuator • Actuating radius adjustable using a hexagonal keywrench 2.5 mm A/F (a and b), minimum 25 mm at 90°to the plane of the actuator and minimum 38 mm in line with the plane of the actuator• The axis of the hinge should be 11 mm above the topedge of the safety switch and in the same plane • The axis of the hinge should be 14 mm above the topedge of the safety switch and in the same plane• Max. 200 Ncm tightening torque for fixing theactuator 40ø11ø4,2

Rmin.150 Rmin.150

14 14

814 37,3 11
