Ex switchgearSafety switches Safety switches with separate manufacturer of actuator EEx AZ 16 range 1. 1.1 1.1.2 Straight actuator AZ 15/16-B1
5640 5

Rmin.150 Rmin.150

28,3

5 5

27ø5,516 Adjustable actuator AZ 15/16-B2
• For very small actuating radii in line with the plane of the actuator• Actuating radius adjustable, minimum 45 mm, using a hexagonal key wrench 2.5 mm A/F (a) • For very small actuating radii at 90°to the plane of the actuator• Actuating radius adjustable, minimum 32 mm, using a hexagonal key wrench 2.5 mm A/F (b) • The axis of the hinge should be 11 mm above the topedge of the safety switch and in the same plane • The axis of the hinge should be 11 mm above the topedge of the safety switch and in the same plane • Particularly suitable for industrial sliding doors• Minimum actuating radius on hinged guards 150 mm• The axis of the hinge should be 5 mm above the topedge of the safety switch and in the same plane

Rmin.45

11

Adjustable actuator AZ 15/16-B3

Rmin.32

11

10
