Ex switchgearSafety switches Protection switches with separate actuator EEx AZ 16 range 1. 1.1 1.1.2

Version withM 5 nuts • For front mounting of safety switch, e.g. on sheet-steel covers• Suitable for use with actuators suppliers AZ 15/16-B1, -B2, -B3 and -B6• Nuts cannot be retro fitted • Ordering suffix -1762 Cable length 2 metres longordering suffix-2m5 metres longordering suffix-5mOrder must always include cable length! To order, select the part number of the desired switch from thetable “Contacts/Switch travel”, e.g. safety switch EEx AZ 16 with one NO and one NC contact, with ejection force and cable 2 m long: EEx AZ 16zvk-2mActuators and accessories must be ordered separately,e.g. straight actuator with ball latch: AZ 15/16-B1-2053The applicable ordering suffix is added at the end of the part number of the safety switch. Further variants not shown here are available on enquiry. Approvals Orderingdetails EC Type Test Certificate: PTB 03 ATEX 1068 X**referring to the switch insert
