Ex switchgearSafety switches Position switches with safety function EEx/EExM 61 range 1. 1.3 1.3.7 Offset professional roller lever with watertight collar WH

Features Legend • Actuating speed 0.5 m/s with an actuatingangle of : Actuating angle from right of switch axis = 40°and = 25°• Plastic roller • Actuator specifications head can be repositioned in steps 4 x 90°• Collar to protect against theentry of dirt : Actuating angle from left of switch axisreferring to lever position as shown in illustration Note Actuation from the left should be avoidedsince this appreciably reduces the mechanical life of the position switch. Change-over contact EExM 61 WH Contacts/Switch travel 1 NO1 NC EEx 61 WH 1Ö/1S
BK 23BN 1124 BK12 BU 2 BNBU14 BK Snap action Slow action Info • Metal roller available

160
