HP1/HPR Compact Power Units Built to meet the tough HTMA standards. HTMA standards so they’ll provide sure Equipped with a high-speed blower and large air-to-oil cooler, our power units provide a source for clean and cool hydraulic power under the toughest operating conditions. All models feature either the powerful Briggs & Stratton Vanguard OHV V-Twin, or Honda OHV GX620 engine. These high-torque engines are fuel efficient, have lower exhaust emissions, yet run quieter than most engines their size. These power units are easy to service too – both the engine and the hydraulic spinon filters are a snap to change. A large readily available commercial battery is fully enclosed in a battery box. OPERATION AND PERFORMANCE HP1 COMPACT HPR ITEM U.S.A. METRIC U.S.A. METRIC Output (2) 5 gpm @ (2) 20 lpm @ 5 or 8 gpm 20 or 30 lpm 2000 psi circuits 140 bar circuit @ 2000 psi @ 140 bar (1) 10 gpm @ (1) 38 lpm @ 2000 psi circuit 140 bar circuit Length 35.5 in. 90.17 cm 35.5 in. 90.17 cm Width 23.25 in. 59.06 cm 23.25 in. 59.06 cm Height 29 in. 74 cm 29 in. 74 cm Weight (less fuel) 276 lbs 125 kg 286 lbs 130 kg Fuel Consumption 1.3 gph 4 lph 1.3 gph 4 lph Engine Lube System Pressure Lube/Low Pressure Lube/Low Engine Oil Shutoff Engine Oil Shutdown Running Gear 12 in. Wheels 31 cm Wheels 12 in. Wheels 31 cm Wheels Retractable Retractable Retractable Retractable Handles Handles Handles Handles Fuel Tank Capacity 4.2 gal. 16 ltr 4.2 gal. 16 ltr Hydraulic Reservoir Capacity 2.7 gal. 10 ltr 2.7 gal. 10 ltr Engine 18 hp Vanguard IC V-Twin (OHV) Stanley Features • Rugged Side Handles Run the entire length of the unit on both sides for easy lifting and protection. • Automatic Throttle Mechanism Provides automatic throttling when the tool is engaged, and return to idle when disengaged. • Sealed No-Maintenance Battery The 35-Ah battery is sealed, non-spillable and requires no maintenance. • Fiberglass Pack Muffler Quiet operation – only 85 db during normal operation. P/N 14530 3/02 • Low Oil Pressure Shutoff A standard feature to protect the engine from low lubrication conditions. • Swing Away Lifting Eye Makes lifting quick and easy using overhead lifting devices. 20 hp Honda (OHV) Equipped with a high-speed blower and large air-to-oil cooler, our power units Stanley's compact power units feature the most efficient hydraulic circuits available in a portable power unit today.
