Stanley Hydraulic Tools 3810 S.E. Naef Road Milwaukie, Oregon 97267 Tel 503•659•5660 Fax 503•652•1780 SPECIFICATIONS ITEM U.S.A. METRIC CAPACITY 13 in. Bar 33 cm Bar PERFORMANCE Concrete and Masonry Cutting FLOW RANGE 7 - 9 gpm 26 - 34 lpm PRESSURE 2000 psi 140 bar PORTS -8 SAE O-Ring WEIGHT (with bar, chain and couplers) 13.7 lbs 6.2 kg LENGTH (with bar and chain) 24 in. 61 cm WIDTH 9 in. 22.9 cm BAR HEIGHT (with Chain) 3 in. 7.6 cm CONNECTION 3/8 in. Flush-Face Quick Disconnect Coupler HOSE WHIPS Yes LUBRICATION/COOLING Internal Water Channels in Bar WATER PRESSURE REQ’D 20 psi min. 1.4 bar min. Features and Benefits The Stanley DS06 Concrete Chainsaw is a lightweight and compact diamond chain saw ideal for cutting concrete, reinforced concrete, concrete block, concrete conduits, brick and other masonry. The combination of power, lightweight and ease of use makes the DS06 ideal for construction, remodeling, maintenance, water and sewer projects. The DS06 has plenty of power to cut through 13 inches of reinforced concrete without stalling. Its design makes straight cuts easy even in confined areas and hard to reach applications. It can plunge cut up to 13-inches for quick cutting of window, door, conduit and duct openings in walls and notching of concrete pipe. It has an effective cutting depth of 11.5-inches for a fullwidth square corner cut. Water for lubrication and cooling is ported through the bar and applied at the point where the concrete is being cut. The trigger activated cooling and lubrication reduces diamond segment, chain chassis and bar wear to decrease cutting cost. The Wall Walker™ is standard equipment. Similar to a bucking cleat, it provides leverage for DS06 easier and straighter cutting. Diamond Chain Saw 34387 07-2004 Visit our website at www.stanley-hydraulic-tools.com
