3
Technical Data Connection diagram >
11071E02 Accessories and spare parts Designation Description Ordering code Parameterising set IS pac - Wizard The
professional software is used to commissioning, configuration and diagnosis on the ISpac Isolators Series 9146, 9162 and 9182. The configuration is by means of an IBM compatible standard
PROFESSIONAL PC.The user is guided through the device configuration process via a user
professional interface designed comfortably, combined with a full context-sensitive online help feature. An online diagnostic window (device self test, process variable
professional display etc.) is also available.
For further information see operating instructions. Supplied: as CD-ROM; Parameterising software incl. parameterising
professional cable.System requirements:•IBM compatible PC with MS Windows 98, NT, 2000, XP•CD-ROM drive
•RS 232 C interface 9199/20-01 Dimension drawings (all dimensions in mm) - subject to alterations Dimension XScrew terminals108 mmSpring
workholding terminals128 mmInsulation displacement connectors131 mm >
09685E00 General Catalogue 12.01.2007 3/4
