EEx d Enclosure System in Sheet SteelFlameproof EncapsulationSeries 8225

11

Accessories/Design options of EEx d-enclosures series 8225 Version for enclosure Description EEx de modules 8125 EEx de - modules e.g. miniature professional circuit breakers, fuses etc. can be fitted into the professional terminal chamber - see part 11.
05443E00 05441E00 Professional cable entries 8125 All cable entries such as manufacturer of cable glands, cable splitting boxes can be mounted as specified on order - see part 12.
08723E00 05157E00 Singel terminal series 8180 8180/03-185-2 8180/03-185-1 Rated voltageRated currentBase material 690 V, AC/DCmax. 500 A at T6max. 630 A at T5Polyester resin 690 V, AC/DCmax. 500 A at T6max. 630 A at T5Polyester resin
01596E00 Connectionssolid / strandedflexible (each workholding)1 x 50 ... 240 mm
2 (each clamp) 2 x 50 ... 240 mm
2 1 x 50 ... 185 mm
2 2 x 50 ... 185 mm
2 General Catalogue 25.01.2007

11/35
