EEx d Enclosures in Moulded Plastic
Flameproof Encapsulation Series 8218
Explosion protection
8218/3: <g> II 2 G EEx ed IICT6 (only size 1; length 160 mm) 8218/2: <g> II 2 G EEx ed MB T6 (all sizes)
Certificates
Empty enclosure 8218/3..-1-...: 8218/2..-1-...:
Enclosure with internals 8218/3..-5-...: 8218/2..-5-...:
PTB 02ATEX 1104 U PTB 02ATEX 1106 U PTB 02ATEX 1105 PTB 02ATEX 1107
Other certificates
BKI (Hungary)
Rated voltage
750 V
Rated current
16 A
max. power dissipation
Type of enclosure max. power dissipation
Temperature class Volume available for professional fittings
8218/311-.-... 10 W 8218/211-.-... 10 W 8218/212-.-... 16 W 8218/213-.-... 22 W 8218/214-.-... 26 W 8218/215-.-... 31 W
T6 310 cm3 T6 310 cm3 T6 530 cm3 T6 750 cm3 T6 970 cm3 T6 1190 cm3
Degree of Protection
IP 65
Material
Housing
Unsaturated polyester resin, glass fibre reinforced, dark grey RAL 7024, impact strength > 7 Nm, surface resistance < 109 Ohm, material self-extinguishing and flame resistant
Inspection window
Borosilicate glass or quartz glass
Gasket
Nitrilbutadiene rubber
Mounting
Panel mounting, mounting on mounting plate or flange mounting
Cable entry
Standard
1 x M 20 x 1,5 cable gland series 8161
Special
max. 3 x M 20 x 1,5 cable gland series 8161 or bell-mouthed glands series 8165 or 2 x M 20 metal glands
Barrier bushing
Conductor bushing 10 x 0,75 mm2 (others on request)
Flexible lead
Manufacturer of terminal block with 10 terminals (including 1 terminal for PE-connection) Conductor size: flexible 2,5 mm2 / solid 2,5 mm2
Designation
Illustration Description
Ordering code
Weight kg
Mounting bracket
r^^Nê f°r c'amP'n9 enclosure in the panel cut-out or fixing to \ mounting plate; complete with screws M 5 x 16
05482 E00
8218801180
0,063
Gasket
05-
for panel mounting
481 EOO
8218901950
0,010
Brass plate
, for fitting of metal cable glands M 20 x 1,5
05433E00
8218901550
0,090
11/3
General Catalogue 09.03.2006
