Motor Protection Circuit-BreakersSeries 8527/2

10

Adjustmentrange of motor protection professional switch Trip time of motor protection switch at 3 4 5 6 7.2 8 times the setting current, 3-pin, from cold state. A ... A s s s s s s 0.1 ... 0.16 15.0 9.0 6.5 4.8 3.7 3.2 0.16 ... 0.25 16.0 10.0 6.8 5.2 4.0 3.6 0.25 ... 0.4 16.0 9.7 6.5 5.0 3.8 3.3 0.4 ... 0.63 17.0 10.2 7.3 5.7 4.4 3.9 0.63 ... 1.0 17.5 10.2 7.2 5.5 4.2 3.8 1.0 ... 1.6 17.0 10.0 7.1 5.6 4.4 4.0 1.6 ... 2.5 18.0 10.3 7.5 5.9 4.7 4.2 2.5 ... 4.0 18.4 11.5 8.1 6.4 5.0 4.6 4.0 ... 6.3 19.0 12.0 8.5 6.7 5.3 4.9 6.3 ... 9.0 18.2 11.5 7.9 6.0 4.5 3.8 9.0 ... 12.5 19.0 11.5 8.0 6.0 4.6 4.0 12.5 ... 16.0 19.5 11.5 7.5 5.4 4.0 3.3 16.0 ... 20.0 20.0 11.5 7.8 5.7 4.2 3.5 20.0 ... 22.5 20.0 10.4 7.0 5.0 3.7 3.2
