Load and Motor SwitchesSeries 8511

10

Selection table Version SchematicDescription Rated current P at 400 V AC 3 Compression glands Ordering code Weight kW kg 8511 Load and motor switches 16 A 7.5 2 x M 25 x 1.5 8511/1-102 1,400 25 A 11 2 x M 32 x 1.5 8511/1-103 1,900
08790E00 ON-OFF switches (0 - I) 3-pole with N-terminal 16 A 7.5 2 x M 25 x 1.5 8511/1-602 1,500 25 A 11 2 x M 32 x 1.5 8511/1-603 1,700
08791E00 ON-OFF switches (0 - I) 4-pole 16 A 7.5 2 x M 25 x 1.5 8511/1-502 2,400 25 A 11 2 x M 32 x 1.5 8511/1-503 1,500
08792E00 Reversing professional switch (1 - 0 - 2) 3-pole Add. to ordering code Modifications to standard design are available, e.g. red professional handle with yellow collar for EM-STOP function, different professional cable entries – specify on order Technical Data Explosion protection Professional gas explosion protection E II 2 G EEx ed IIC T6 Dust explosion protection E II 2 D IP65 T 80 °C Certificates Gas explosion protection PTB 01 ATEX 1024 (certificate type 8146/5) Dust explosion protection LCIE 02 ATEX 6241 (see type 8146/5) Other certificates CSA (Canada); FM, UL (USA); VNIIEF (Russia) Main contacts max. 8-pole Type/Size 8511/1-.02 16A 8511/1-.03 25A Rated working voltage 690 V , AC 690 V , AC Rated operating current 16 A 25 A Switching capacity AC 3 to IEC / EN 60 947 AC 3 to IEC / EN 60 947 UP230 V400 V 500 V690 V4.0 kW7.5 kW 7.5 kW11 kW UP230 V400 V 500 V690 V5.5 kW11 kW 15.0 kW22.0 kW Back-up fuse 50 A, gL 50 A, gL Terminals 4/6 mm
2 , flexible/solid 6/10 mm
2 , flexible/solid Professional housing polyester Switch handle in 0-position padlockable in 3 positionsColour: handle black, collar blackSpecial: red handle, collar yellow (EM-STOP function) Degree of protection IP 65 Life > 10 Operations Ambient temperature - 20 °C ... + 40 °C
General Catalogue18.01.2006

10/ 2
