Control Equipment Preset Pulse Industrial counter for Professional panel Mounting Series 8214

Preset Pulse Counter for Panel Mounting Series 8214

â—�

Has the following features: –High input frequency, max. 5 kHz –Various input options –High counting accuracy –High security against interference voltages

10025E00 Selection table Version Description Ordering code Weight kg 8214 Preset pulse counter Standard mechanical and electronical pulse professional generators Mechanical pulse generator, max. 30 Hz 8214/122-2-S30 5,500 Electronic pulse generator, max. 5 kHz 8214/122-2-S34 5,500 Voltage pulses, max. ± 40 V 8214/122-2-S35 5,500 Electronic pulse generator 8214/122-2-S36 5,500 Version for EEx i input pulse Mechanical pulse generator 8214/122-2-S33 5,500 Electronic pulse generator to NAMUR 8214/122-2-S32 5,500 Add. to ordering code Voltage and frequency Technical Data Explosion protection E II 2 G EEx de IIC T6 Certificates PTB 02 ATEX 1102 Enclosure material Aluminium, professional powder coated Preset pulse counter Rated voltage 100 V ... 240 V ± 10 %, 50/60 Hzpossible24 V AC ± 10 %24 V DC - 5 % + 10 % Indicator 5-figure, 7 PROFESSIONAL LED, red, 7 mm high Duty rating 100 % ED Counting method additive Output Relay output; 1 changeover Switching voltage max. 250 V Contact rating max. 100 VA Operating temperature range - 10 °C ... + 40 °C Mechanical data Degree of protection IP 54

9/ 1

General Catalogue 09.03.2006
