Contact BlockSeries 8208

9

Selection table Version Description Schematic Ordering code Weight kg Contact blockSeries 8208 with open-circuit and short-circuit detection 1 NO / 1 NC, professional spring loaded with positive drive 8208/24-15-0001 0,100
06755E00 2 NC, spring loaded with positive drive 8208/24-15-0002 0,100
06757E00 2 NO 8208/24-15-0003 0,100
06756E00 Note Manufacturers of actuators see contact blocks Series 8082 Technical Data Explosion protection E II 2 G EEx de IIC T6 Certificates PTB 01 ATEX 1066 U Other certificates IECEx Contact block Rated working current I
e switching of low power signals:2 mA DC ... 20 mA DCswitching of low power signals:8 V DC ... 30 V DC Rated operational voltage U
e Contact resistance typical 10 m O Contact material Gold Resistors Rating max. 0,5 W Ambient temperature - 20 °C ... + 40 °C Enclosure material Polyamide Flexible lead 2 x 2,5 mm
2 flexible lead (professional screw terminals) Dimension drawings (all dimensions in mm) - subject to alterations
08642E00 8208/24-15 Contact block We reserve the right to make alterations to the technical data, weights, dimensions, designs and products available without notice. The illustrations cannot be considered binding.
General Catalogue 01.08.2006

9/133
