Portable Lamps
Series HS6145 and HSL145
Technical Data
Charging unit
Version 6145/92 L145/92 6145/91 L145/91 L145/96 6145/93 L145/93 6145/2
Application for stationary
installation,
withemergency light
function
for stationary
installation,
without emergency
light function
for stationary
installation,
without
emergency
light
function
(halve
charging
current)
for installation into
vehicles without
emergency light
function
integrated
into
light fitting
Attention:
Not for use in hazardous areas.
Battery charging outside of hazardous area.
Attention:
Not for use in
hazardous areas.
Battery charging
outside of hazardous
area.
Charging
only
outside
hazardous
area
Housing Moulded material, black, acid and caustic resistant,
self extinguishing
Moulded material,
black, acid and caustic
resistant,
self extinguishing
Moulded
material,
black,
acid and
caustic
resistant,
self extinguishing
Main cable Length: 2 m; Europlug Length: 2 m Length:
2 m;
Europlug
and
coupler
Function
Charging starts when lamp is fitted into charger Charging starts when
lamp is fitted into
charger
Charging
starts
when
main
cable is
plugged
LED
charge
indicator
no
indicator
LED charge indicator no
indicator
LED charge indicator – –
Emergency light function acc. to VDE 0108;
if power supply is
switched off, lamp
fitted in charging unit
becomes effective
automatically
without without possible,
together
with
9145/92
Rated voltage 230 V, AC
50 Hz / 60 Hz
230 V, AC
50 Hz / 60 Hz
12 V / 24 V, DC
(selectable)
230 V, AC
50 Hz /
60 Hz
Protection class II (all - insulated) II (all - insulated) III (Extra-low voltage) II (all -
insulated)
Charging time 230 V AC: 14 h 230 V AC: 14 h 12 V DC: 14 h; 24 V
DC: 25 h
230 V AC:
14 h
Charging current
Constant-current Constant-current Constant-current Constantcurrent
230 V AC: 700 mA 230 V AC: 700 mA 230 V AC:
350 mA
12 V DC: 700 mA; 24 V
DC: 400 mA
230 V AC:
700 mA
Protection category IOI
0.51 Ah/day (Charge 1/2h at 700 mA, 16 h interval)
Installation free installation or wall mounting possible
Interference suppression acc. to VDE 0875
