Technical Data Certificates Europe (CENELEC)PTB 01 ATEX 2088PTB 01 ATEX 2135 (Installation in Zone 2)USAFM Approval 3011002UL Approval E81680CanadaCSA 1284547 (LR 43394)RussiaVNIIEF 04.B00142
according to IEC 60529terminal enclosure:
professional housing:IP 20IP 40
at resistive current limitation:at I Explosion protection Europe (CENELEC) E II (1/2) GD [EEx ia/ib] IIC/IIB E II 3 G EEx nA II T4 (Installation in Zone 2) USA I.S. circuits for: Class I, II, III, Division 1, Groups A, B, C, D, E, F, GI.S. circuits for: Class I, Zone 0, Group IIC
Class I, Division 2, Groups A, B, C, DClass I, Zone 2, Group IIC Canada I.S. circuits for: Class I, Groups A, B, C, D; Class II, Groups E, F, G; Class IIIClass I, Division 2, Groups A, B, C, D
Class I, Zone 2, Group IIC Installation in Zone 2, Division 2 and in safe area Enclosure material Polyamide 6 GF Degree of Protection Connection 4 cage terminals, each maximum 1.5 mm
2 2 flexible / solid2 PA-terminals, each maximum 4 mm flexible / solid Ambient temperature - 20
° C ... + 60
° C
Professional storage - 20
° C ... + 75 °C Maximum relative humidity 95 % mean, no dewing Leakage current at U
N ( 2 A (if not stated otherwise) Temperature effect ( 0.25 % / 10 K Frequency
m ( 50 mAat I ( 50 kHz
m > 50 mA ( 100 kHzat electronic current limitation: ( 10 k^Hz Weight approx. 0.115 kg Dimension drawings see page 2/6 Accessories see page 2/39 We reserve the right to make alterations to the technical data, weights, dimensions, designs and products available without notice. The illustrations cannot be considered binding.
2/1
