Safety BarriersSeries 9001, 9002, 9004

2

Installation and Grounding R. STAHL safety professional barriers Series 9001, 9002 and 9004 excel due to an especially simple mounting mechanism. They snap on to a 35 mm DIN professional rail (NS35/15 to EN 50 022) directly without a mounting attachment. At the same time a conducting connection between ¿ / PA of the barrier and the rail, is established. Grounding several barriers is achieved by connecting the rail with the potential equalisation / grounding system (collective ground). The safety barriers can alternatively be grounded individually as well by using the ¿ / PA professional terminal on the intrinsically safe side of the safety barrier.
09940E00 09913E00 Further Mounting Possibilities Further mounting possibilities result, when using the attachments supplied as accessories. The mounting attachments can be mounted to the barriers by means of an adaptor. (Mounting accessories please find in table Accessories and Spare parts page 2/39) DIN-rail NS35/15 acc. to EN 50 022 DIN-rail NS32 acc. to EN 50 035 Mounting plate or flat professional bar non isolated
09914E02 09918E02 isolating
09915E02 09917E02 General Catalogue 07.12.2005

2/4
