| | | | | | | | | | | | | | | | | | | | Sr—n Digital Output Module [^51 Series 9475 from Rev. F | | | | | | | | | | | | | | | | | | | | | | | | | | | Version | Channels | Safety data Ex ia IIC | Digital Input (Plant-STOP) | Ordering code | | Weight | | | | | | max. voltage Uo | max. current lo | | | | kg | | | | Digital Output Module | 4 | 19.9 V | 150 mA | no | 9475/12-04-11 | 0,275 | | | | | | 26.2 V | 110 mA | no | 9475/12-04-21 | 0,275 | | | | | | 26.2 V | 90 mA | no | 9475/12-04-31 | 0,275 | | | | | | 26.2 V | 110 mA | yes | 9475/22-04-21 | 0,275 | | | | | 8 | 11.5V | 75 mA | no | 9475/12-08-41 | 0,275 | | | | | | 19.9 V | 145 mA | no | 9475/12-08-51 | 0,275 | | | | | | 26.2 V | 107 mA | no | 9475/12-08-61 | 0,275 | | | | | | 19.9 V | 145 mA | yes | 9475/22-08-51 | 0,275 | | | | | | 26.2 V | 107 mA | yes | 9475/22-08-61 | 0,275 | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | Technical Data | | | | Safety data for outputs | | | | | | | | | | Certificates | PTB 99 ATEX 2220 | | | | | | | | Other certificates | lECEx, USA (FM), Canada (CSA), Shipping (DNV) | | | | | Explosion protection | | | | | | | | | | Gas explosion protection | <g> II 2 (1) G EEx ib [ia] IIC/IIB T4 | | | | | | | Dust explosion protection | <g> II (1/2) D [ExiaD/ibD] | | | | | | | | EExib IIC | Type | Uo[V] | lo [mA] | Po [mW) | Lo [mH] | Co [nF] | | | | | 9475/12-04-11 | 19.9 | 60 | 714 | 1.30 | 223 | | | | | 9475/12-04-21 | 26.2 | 60 | 722 | 1.45 | 97 | | | | | 9475/22-04-21 | | | | | | | | | | 9475/12-04-31 | 26.2 | 60 | 585 | 2.44 | 97 | | | | | 9475/12-08-41 | 11.5 | 50 | 216 | 6.70 | 1640 | | | | | 9475/12-08-51 | 19.9 | 38 | 558 | 1.44 | 223 | | | | | 9475/22-08-51 | | | | | | | | | | 9475/12-08-61 | 26.2 | 30 | 565 | 1.57 | 97 | | | | | 9475/22-08-61 | | | | | | | | | EEx ia IIC | Type | Uo[V] | lo [mA] | Po [mW) | Lo [mH] | Co [nF] | | | | | 9475/12-04-11 | 19.9 | 150 | 742 | 1.30 | 223 | | | | | 9475/12-04-21 | 26.2 | 110 | 722 | 1.45 | 97 | | | | | 9475/22-04-21 | | | | | | | | | | 9475/12-04-31 | 26.2 | 90 | 585 | 2.44 | 97 | | | | | 9475/12-08-41 | 11.5 | 75 | 216 | 6.70 | 1640 | | | | | 9475/12-08-51 | 19.9 | 145 | 719 | 1.44 | 223 | | | | | 9475/22-08-51 | | | | | | | | | | 9475/12-08-61 | 26.2 | 107 | 697 | 1.57 | 97 | | | | | 9475/22-08-61 | | | | | | | | | Safety data for digital input | for deactivating all outputs ("Plant-STOP") | | | | | | EEx ia IIC | only type | U0[V] | lo [mA] | Po [mW) | Lo [mH] | Co [nF] | | | | | 9475/22-04-21 | 6.6 | 67 | 110 | 8.24 | 22.000 | | | | | 9475/22-08-51 | | | | | | | | | | 9475/22-08-61 | | | | | | | | | Further information | see certificates | | | | | | | | | | | | | | | | | | | | | | | | | | | 4/49 | | | | | | General Catalogue 18.08.2006 | | | | | | | | | | | | | | | | | | | | | | | |
|
