Lighting - 9224 installation equipment

1 Control equipmentSeries 8040Plugs and socketsSeries 8570Junction boxesSeries 8102/8118Installation switchSeries 8030/51Safety distributorswitchSeries 8146Terminal boxesSeries 8146/8125 Description Type of protection > IP65Series 8030/8040 > installation switch series 8030 and control equipment series 8040 are designed for the switching of circuits > IP66/67Series 8102/8118
2 > IP55/66Series 8570 > IP65Series 8146 > junction boxes 8102/8118 and terminal boxes of the 8146/8125 series enable safe distribution and connection
3 > plugs and sockets in the 8575 series facilitate mobile power supply
4 > safety distributor switches/automatic circuit breakers of the 8146 series serve to protect and safeguard electrical circuits – can be safely switched on/off in the hazardous area Applications
5 > for switching, distributing and safeguarding of electrical circuits in hazardous areas > installation equipment and lighting all from the same reliable source – the complete solution advantage from R.STAHL!
Zone 1, Zone 2Zone 21, Zone 22 EN,IEC 8030/8040II 2 G, EEx de IIC T68102/8118/8146II 2 G, EEx e II T6 8570II 2 G, EEx de IIC T6II 2 D, IP 66 T 80°C8146II 2 G, EEx de IIC T4all seriesII 2 D, IP 65/66 T Omax* *Temperature class or maximum surface temperaturedepends on lamp selection
