PalletPal Level Loaders, Turntables, Rotators/Inverters and Transporters

Load and Unload Pallets the Faster, Safer and Easier Way Loading and unloading pallets is time consuming, back breaking work that can lead to excess worker fatigue or even injury. PalletPal Level Loaders make the job faster, safer and easier. They position pallets at a comfortable working height virtually eliminating bending, reaching and stretching when building or breaking down pallet loads. Turntable equipped units allow users to spin the load so they are always working on the near side eliminating the need for walking around pallets while carrying heavy loads and removing the potential for...

PALLETPAL 360 FULLy AUTOMATIC SPRINg-ACTUATED CTUATED ® Ideal for Most Applications With inherent stability and no power sources or connections, the fully automated mechanical PalletPal® 360 is virtually maintenance-free. The turntable is easily rotated even when fully loaded and allows for nearside loading and unloading without walking around the unit. Exclusive PalletPal base design keeps all components within the diameter of the turntable ring offering workers complete 360˚ access to loads with no reach-over zones. Heavy-duty springs bring pallet to most convenient height. Best used with uniform...

POWERED PALLETPAL When loads, weights, pallet sizes or product dimensions vary greatly, a Powered PalletPal® with total operator control is the solution. A foot control allows the operator to adjust the load to an infinite number of positions up to 32¾" (plus pallet), so it is always at the most comfortable height for loading and unloading. The manual turntable allows quick and easy rotation of the load so that the operator is always working on the near side, eliminating reaching, stretching and walking around. Built-in fork pockets provide both ease of portability and additional stability. hyDRAULIC...

For Use with hand Pallet Trucks With internal hydraulic power, PalletPal® Roll-On™ Level Loaders lower to floor height so pallets can be rolled on and off with a hand pallet truck. The lift is then easily adjusted by pushbutton or foot switch control to maintain an ideal height for manual loading and unloading. The narrow side and back panels provide easy reachover for four sided-access. Now available with One Touch Auto Leveling Allows the operator to “dial-in” the exact increment of travel for loading or unloading. It will also return the platform to full height (or to fully lowered position)...

PALLETPAL MObILE LEVELER/STACkER ® Perform multiple tasks with one versatile machine. Used by itself as a mobile pallet positioner or as a companion to your PalletPal, the mobile leveler can deliver and remove loads quickly and easily without the expense of a ride-on fork truck. The straddle design accepts any pallet or skid. A single PalletPal Mobile Leveler can feed multiple PalletPals. Comes with 115V battery charger and is available with automatic load leveling eye. FORk OVER For use with skids and open or closed bottom pallets to 40" wide OVERALL DIMENSIONS LOWERED HEIGHT RAISED HEIGHT FORK...

STACK-N-GO™ POWER DRIVEN STACKERS These versatile multi-purpose machines are ideal for transporting loads on pallets, stacking loads, servicing rack or shelving up to 7' high or as an adjustable height workstation for loading and unloading pallets. Dual stage units will lift a 2,500 lb. load up to 90" (single stage units lift 3,000 lbs. up to 43"). Unique narrow mast and offset handle provide maximum operator visibility. Available in fork over or straddle styles. Ideal for use in light manufacturing, warehousing, assembly and even retail facilities. FORK OVER For use with open bottom pallet or...

Restack Pallets the Faster, Safer, With the ability to handle pallet loads PalletPal® Pallet Rotator/Inverter is a simple, rugged machine designed to invert entire pallet loads. The pressure adjustable clamping mechanism easily secures loads up to 4,400 pounds and rotates them 180 degrees on a massive anti-friction turret bearing. Uses include: • Replacing broken pallets • Switching loads to/from in-house • Transferring from pallets to slip sheets • Replacing damaged goods at the No matter what the application, a PalletPal Rotator/Inverter is faster, safer, and easier than manual restacking of...
