47 UTS Series Description Fibre optic contacts Size 16 Fibre optic contacts for TRIM TRIO® connectors Size 16 Fibre optic contacts are optical contacts designed for the integration of optical links in all TRIM TRIO® cable connectors. The Fibre optic contacts are designed to accommodate: • Plastic Optical Fibre (POF) 1 mm core and 2.2 mm jacket • Plastic Clad Fibre (PCF) 230ìm core and 2.2 mm jacket • Multimode Silica Fibre 62.5/125ìm type 2.0 mm max. jacket • Singlemode Silica Fibre 9/125ìm type 2.0 mm jacket Typical features and benefits are: • Socket contact is spring loaded to avoid any air gap between the two optical faces. • Low insertion loss is provided by high precision pieces. • Single jumpers, multiway harness and active device housings can be supplied regarding customer requirement. Technical characteristics Performance • Fibre type: POF/PCF Multimode Singlemode 62.5/125µm 9/125µm • Wave length: 650 nm 1300 nm 1310 nm • Optical insertion loss (typ.): 2 dB max. < 0.5 dB < 0.35 dB • Jacketed external diameter: 2.2mm 2.0mm max. 2.0mm max. • Temperature range: -25°C to +70°C -25°C to +70°C -25°C to +70°C • Cable retention: 49N • Mating cycles without cleaning: 50 • Max. mating cycles: 500 Construction • Contact body: Copper alloy Connector accommodation Any TRIM TRIO® size 16 contact can be used in any contact position in any connector in the TRIM TRIO® size 16 interconnection system : UTP, UTS, UTG, UTO. Contacts
