Applications

The Sonobond RingMaster™ isused for applications requiring bonding of felted filter media to circular plastic components. Using ultrasonic technology, the equipment produces a depend- able 360°bond, creating heavy- duty bags for chemical and liquid filtration applications. Filter components produced by Sonobond’s RingMaster are used in a variety of industries, including food, paper, pharma- ceuticals, and petroleum, for applications such as removing undispersed solids, filtering condensate, and removing plastic fines from water.

Theory of Operation

Ultrasonic bonding is accomplished by channeling high-frequency vibrations, via a welding head, at the interface of the plastic part and felted filter media. The vibrations create a rapid heat buildup, causing the synthetic materials to melt and industrial fuse. The result is a strong, dependable, ultrasonic bond that is achieved without adhesives, which require drying time, or thread, which create perforations that affect product reliability.

Specifications

Electrical: 220 Volts, 50 amps, 50/60 Hz, single phase

Ordering Information

RingMaster Model 20RM Compressed air: Clean dry air at 90 to 105 psi, 8 CFM Weight: Approximately 3,000 lbs. Size: 72 x 48 inches base by 69 inches high
Specifications are provided for information only and are believed to be accurate. However, no responsibility is assumed by Sonobond Ultrasonics for their use. Ongoing product development and improvement may cause changes without notice. SONOBOND ULTRASONICS, INC. 1191 McDermott Drive • West Chester, PA 19380 Phone: 800-323-1269 • 610-696-4710 • Fax: 610-692-0674 Internet: www.SonobondUltrasonics.com E-mail: Sales@SonobondUltrasonics.com
© 2004 Sonobond Ultrasonics
