4

For ordering

See valve specification system.

Valve specification system

CHECK VALVE - 5896 BCV - A 5 - A A Z - N 1 1 - DN… - PN…

1234567891011

1 Valve type 4 Material - valve body 7 Material - shafts

BCV = With spring A = CF8M N = 1.4460, Nickel coated BCVA = Without spring

5 Material - disc 8 Bearings - valve body/shafts 2 Valve body design

A = CF8M 1 = Without bearing A = Wafer type

6 Material - seat ring 9 Sealings - shafts 3 Nominal pressure

Z = Integrated seat 1 = Graphite 5 = PN 25

10 Valve size DN 11 Drilling, counter anges
