28 Accessories and spares
Extension cables Grade 0 granitebased stand
Analogue extension cables LVDT (m) 1, 2, 5, 10 Half bridge (m) 1, 2, 5, 10 Digital data cable and screwlock kits Standard (m) 2, 5 Enhanced (m) 0.3, 2, 5, 10, 15 For Gauging Probe: DP/1, DP/2, DP/5, DP/10 For Linear Encoder: LE/12, LE/25 Base Height (mm)48.5 Base Width (mm)120.0 Base Depth (mm)160.0 Total Height (mm)238.5 Column Adj. Range (mm)150.0 Column Diameter (mm)25.0
Plug viewinto pins 12435 Weight (kg)3.7Standard extension cables are fitted with a 5 pin270DIN socket and a 5 pin 270plug, and are
designed to be used with Solartron
Metrology
standard product
11.50 60 ° 9.50 8.00 1.00 M4 X 0.7 8 . 50 5.75 1.50 5.50 Radial outlet
00 . 8 To convert cableoutlet from axial to
radial on analogue
and digital gaugingprobes For mounting 8mm analogue and digitalgauging probes
00 . 30 Adjusting spanner
For adjusting the pre-travel on gauging probes
3 . 50 Springs Gaiters
Replacement springs for analogue gauging probes Replacement gaiters for analogue and digital
gauging probes and linear encoders
