| 1 Probe Accuracy The accuracy of the LVDT and Half Bridge industrial probes is quoted as % of reading or urn, which ever is greater. The accuracy of the Digital Probe range is quoted as [(resolution) + (accuracy %) x D] where D is the distance fror the setting raster. (Please refer to the Glossary for definitions) 2 LVDT and Half Bridge Probe Performance Accuracy, sensitivity and energising current are valid for the following calibration conditions: LVDT probes calibrated at 3 V 5 kHz frequency into a 10 kn load or 100 kn for the unplugged versions. Half Bridge probes calibrated at 3 V 10 kHz frequency into a 2 kn load or 1 kn for the unplugged versions. The probes will operate with energising voltages in the range 1 V to 10 V and with frequencies in the range 2 kHz to 20 kHz but the perforrance is not specified. 3 Viton is a trademark of DuPont Dow Elastomers. 4 Cables All probes are supplied with 2 m of PUR cable as standard. Other lengths and options such as nylon braided, metal braided and armoured are available on request. 5 Digital Probe Termination Digital Probes are terminated with Solartron's Probe Interface Electronics (PIE) module. Please refer to the Orbit Network for details on this module and methods of integration for Digital Probes. 6 Below 0 C environment must be dry |
