Features • ±3% output voltage regulation • Noise attenuation - 120 dB common mode - 60 dB transverse mode• Surge protection tested to ANSI/IEEE C62.41 Class A & B Waveform: - <10 V let through typical • Acts as a step-up or step-down transformer • Harmonic filtering • Hardwired • Galvanic isolation provides exceptional circuit protection.• 25 year typical MTBF• No maintenance required

MCR Hardwired - Power Line Conditioning with Voltage Regulation - 20950 1 Power Protection and Conditioning

Applications • Industrial automation and control equipment PLCs • Machine tools • Computer loads and electronic equipment • Robotics • Semiconductor fabrication equipment

MCR Hardwired Series – Power Line Conditioning with Voltage Regulation

The MCR Hardwired Series provides excellent noise filtering and surge protection to safeguard connected equipment from damage, degradation or misoperation. Combined with the excellent voltage regulation inherent to SolaHD’s patented ferroresonant design, the MCR can increase the actual Mean Time Between Failure (MTBF) of protected equipment. The MCR is a perfect choice where dirty power, caused by impulses, swell, sags, brownouts and waveform distortion can lead to costly downtime because of damaged equipment. Related Products • On-line UPS (S4K Industrial) • Surge Protection • Three Phase Power Conditioners • Active Tracking

Filters Selection Tables: Single Phase

Group 2 – MCR Series, 60 Hz Only

VACatalog NumberVoltage InputVoltage OutputHeight (inch)Width (inch)Depth (inch)Ship Weight (lbs)Design StyleElec Conn 120 63-23-112-4 120, 208, 240, 480120945151D250 63-23-125-4 120, 208, 240, 4801201068271D500 63-23-150-8 120, 208, 240, 480120, 208, 2401397371E750 63-23-175-8 120, 208, 240, 480120, 208, 2401497521E1000* 63-23-210-8 120, 208, 240, 480120, 208, 2401797621E1500* 63-23-215-8 120, 208, 240, 480120, 208, 24017139951E2000* 63-23-220-8 120, 208, 240, 480120, 208, 240181391091E3000* 63-23-230-8 120, 208, 240, 480120, 208, 240191391421E5000* 63-23-250-8 120, 208, 240, 480120, 208, 240281392221E7500** 63-28-275-8 208, 240, 480120, 208, 240272693622F10000** 63-28-310-8 208, 240, 480120, 208, 240282694462F15000** 63-28-315-8 208, 240, 480120, 208, 2402838107103F * Canadian option: cULus certified units must be ordered by changing “-8” (UL only) to “-C8”.** UL Listed Only. Use Group 3 for cULus.
