SELF TAPPING SPACER SERIES 315
• Made from special hardened steel • Colour: nickel plated, zinc plated • Excellent electrical conduction by special copper / nickel casing • No closing washers or nuts necessary because of self-tapping thread • Very suitable for metal sheets, aluminium and nylon • Hole diameter 2.70 mm (+0.00/- 0.05) for M3 • Hole diameter 3.6 mm (+0.00/-0.05) for M4 Examples of use Dimensions Dimensions in mmPrices in Sterling per unit
Article number GramCol A B C D E F Price Per Price Per Price Per
315 3051 400 58 1.09 M3 5.5 5 5 3 2.70 87,65 1000 56,75 500 16,00 100 315 3081 400 58 1.56 M3 5.5 8 5 4 2.70 95,77 1000 59,61 500 15,56 100 315 3101 400 58 1.87 M3 5.5 10 5 6 2.70 100,63 1000 62,64 500 16,35 100 315 3121 400 58 2.18 M3 5.5 12 5 8 2.70 105,50 1000 65,67 500 17,15 100 315 3151 400 58 2.70 M3 5.5 15 5 8 2.70 113,62 1000 70,73 500 18,46 100 315 4100 410 58 3.24 M4 7 10 8 6 3,6 129,62 1000 80,69 500 21,06 100 315 4150 410 58 4.55 M4 7 15 8 8 3,6 156,02 1000 97,12 500 25,35 100 315 4200 410 58 5.94 M4 7 20 8 8 3,6 183,83 1000 109,84 500 28,95 100 315 4250 410 58 7.71 M4 7 25 10 10 3,6 207,77 1000 66,75 250 20,36 50 315 4300 410 58 9.32 M4 7 30 10 10 3,6 234,87 1000 75,45 250 23,02 50
Article numberAll prices are GROSS xxx xxxx xxx XX Article material, see page material informationfor discounts see payment conditions
All prices are indicative. Check www.skiffy.com for our current prices and more information about materials and colours . WWW.SKIFFY.COM · TEL: 01902-894658 · FAX: 01902-894661
