SOLDERING SPACER SERIES 314
• Made from brass • Colour: tin plated • Designed to improve and automate fastening of metal spacers on PCB • Low thermal inertia and tin plated finish • Ideal to mount daughter PCBs on mother PCB • Perfect electrical connection, suitable for EMC applications • To be soldered manually or through a soldering wave Examples of use Dimensions Dimensions in mmPrices in Sterling per unit
Article number GramCol A B C D E F Price Per Price Per Price Per
314 3100 412 50 1.54 M3 5 10 3.5 6 3.1 99,98 1000 62,24 500 16,25 100 314 3058 412 50 1.89 M3 5 12.7 3.5 8 3.1 111,95 1000 69,69 500 18,19 100 314 3150 412 50 2.05 M3 5 15 3.5 8 3.1 117,74 1000 73,29 500 19,13 100
Article numberAll prices are GROSS xxx xxxx xxx XX Article material, see page material informationfor discounts see payment conditions
All prices are indicative. Check www.skiffy.com for our current prices and more information about materials and colours . FAX: 01902-894661 · TEL: 01902-894658 · WWW.SKIFFY.COM
